ZB 700CT-240B Single-Sheet Paper Making Machine With Diversified Functions

ZB 700CT-240B single-sheet paper bag making machine adopts different paper bag types according to the performance of the packaged items. Other paper bags: including archival paper, envelopes, paper, cement bags, feed bags, wax paper bags, fertilizer bags, laminated paper bags, four-layer paper bags, medicine bags, clothing bags, food bags, shopping bags, gift bags, and wine bags. There are many requirements for different uses, including the size of the designed specifications, including the thickness of the paper bag paper. Therefore, it must be customized according to the actual situation to achieve twice the result with half the effort, economical and applicable purposes, and provides material savings, green environmental protection, and corporate capital investment. More protection.
paper : Art paper,special paper, Ivory Board paper. over 190g/听 paper Need Die-cutting In Advance.

    Description

    The CT-B series paper bag machine, as a semi-automatic device, precisely forms paper into tubes with high accuracy. The process includes automatic pasting of top reinforced cards, top folding, tube forming, and pressing, making this model an integral part of Zenbo's modular paper bag machine products. The CT-B series machines can adapt to various types of die-cut paper, including square bottom, split bottom, and V-bottom, enabling stable and efficient tube formation.
    The ZB700CT-240B has a tube pasting length range of 180mm to 240mm and a width range of 50mm to 120mm. It can perform functions such as tube forming for commonly seen small-sized paper bags in the market. The top reinforced card size ranges from 90mm to 220mm in length and 25mm to 40mm in width.

    standard configuration

    standard configuration

    option

    Automatic Top Reinforced cardboard pasting(2pcs), Automatic Top Folding, Tube Forming.

    square Bottom

    split Bottom

    V Fold Bottom

    4pcs Top Reinforce cardboard (F)

    standard configuration (3)p26

    standard configuration (4)go3

    standard configuration (5)467
    standard configuration (6)d5p

    Main Technical parameters

    ZB700CT-240B (1)seh
    Max.sheet (LX w) 720x460mm
    Min.sheet (LX w) 325x220mm
    sheet weight 120-250g/㎡
    Top Folding Depth 30-60mm
    Bag Tube Length 180-430mm
    Bottom width 50-120mm
    Bag width 110-240mm
    Top Reinforced paper weight Top Reinforced paper Length 200-500g/㎡ 90-220mm
    Top Reinforced paper width 25-40mm
    speed 40-70bags/min
    Machine size(LxwxH) 13600x2800x1800mm
    Total/production power 27/18kw
    Voltage 380V
    Total weight 9.6T
    Glue Type water Base Glue And Hot-melt Glue
    standarboc
    Semi-automatic Paper Bag Making Machine0sx
