ZB 700S-250 Single-Sheet Fully Automatic Paper Bag Making Machine Revolutionizes Paper Bag Production
Description
The S series paper bag machine uses Zenbo’s proprietary structure at the handle attachment area, allowing operators to switch from the original side-lying equipment adjustment method to a seated adjustment method. This change reduces operational difficulty and enhances safety.
The standard configuration for the S series includes a folded top with a pasting mechanism, with gluing positions on the large side (bag surface). Optional features include an embedded folded top and gluing positions on the large side (gusset position). If you need the machine to comply with CE standards, please contact us, and we can install additional components to meet CE requirements.
The ZB700S-250 is a machine in the S series primarily used for producing small premium paper bags with handles. To accommodate single sheets of smaller-sized paper, it uses a feeder head with two suction and two delivery points, providing greater stability when feeding small paper sizes.
This machine produces paper bags with lengths ranging from 150mm to 260mm and gusset widths from 60mm to 130mm. It is suitable for mass-producing paper bags for single cups of milk tea and premium gift bags with handles. The bags produced by this machine have no excess creases, making them more aesthetically pleasing.
standard configuration | option 1 |
Top folding Joint Type: Directly pasting Gluing position on Big side (Bag surface) | Top folding Joint Type: Insert pasting Gluing position:small side (Gusset) |
Main Technical parameters
3 Bag Mouth processes | |||
Max.sheet(Lxw) | 770x445mm | 770x405mm | 770x445mm |
Min.sheet(Lxw) | 480x265mm | 480x225mm | 480x265mm |
sheet weight | 120-190g/m2 | 120-190g/m2 | 120-190g/m2 |
Bag width | 150-260mm | 150-260mm | 150-260mm |
Bottom width | 60-130mm | 60-130mm | 60-130mm |
Bag Tube Length | 225-405mm | 225-405mm | 225-405mm |
Top Folding Depth | 40-50mm | —— | 40-50mm |
Handle patch weight | 140-200g/m2 | 140-200g/m2 | 250-350g/m2 |
Handle patch Roll Diameter | Φ1000mm | Φ1000mm | Φ1000mm |
Handle patch Roll width | 60-80mm | 60-80mm | 60-80mm |
speed | 40-70bags/min | Glue Type | water Base Glue And Hot -melt Glue |
Voltage | 380V | Total/production power | 42/25.2kw |
Total weight | 18T | Machine size(LxwxH) | 17500x4100x2950mm |
